Name: Rinnai EF 250EXT LPGINFEF250L
SKU: rinnai080289
Price: 3674.25 NZD
Availability: InStock

Rinnai EF 250EXT LPGINFEF250L

Product Price:

$3,674.25 incl GST

Add to cart

Installed Price

$4,985.00

Confirm Price Now

Rinnai’s most efficient continuous flow gas hot water system. Rinnai INFINITY EF condensing continuous flow gas water heaters effectively capture waste heat from the flue gas through the use of a secondary heat exchanger to help heat the water with less energy.

Suitable for 2 - 4 bedrooms
Suitable for 3 - 7 People
More efficient than other units

Compare

SKU: rinnai080289. Category: Rinnai.

Product Description

Rinnai’s most efficient continuous flow gas hot water system. Rinnai INFINITY EF condensing continuous flow gas water heaters effectively capture waste heat from the flue gas through the use of a secondary heat exchanger to help heat the water with less energy.

Hot water capacity
1.5 to 37 litres per minute

Suitable for
• Commercial and domestic external applications
• Mains and medium pressure systems
• Solar installations as a gas boost

Hard or acidic water will need to be treated in order to use this product.

Gas type
Available for Natural Gas or LPG. Specify gas type at time of purchase.

Clearances
The following diagram has been provided to assist you in determining where (and if) an external continuous flow water heater can be positioned. If in doubt, prior to purchase, consult a licensed gasfitter.

Clearance below eaves, balconies, and other projections, for all models is 300 mm.

* Rinnai recommend 1.5 m to give enough clearance for the pipe work, and to safely expel flue gases.

REU number:	REU-KM3237WD
Factory preset temperature:	55 °C
Rinnai product code:	INFEF250N/INFEF250L

Capacity	Hot water capacity: 1.5-37 litres per minute Nominal water capacity: 32 litres per minute at a 25 °C rise (1920 L/h)
Connections	Hot water outlet: R¾ (20 mm) Cold water inlet: R¾ (20 mm) Gas supply: R¾ (20 mm) Condensate: R½ (15 mm)
Exhaust system	Forced flue
Frost protection	Fitted as standard. Frost protection operates automatically, as long as the appliance is connected to the electrical power supply, by activating when the temperature inside the unit drops below 3.5 °C, and turns off once the temperature inside the unit reaches 7 °C.
Ignition system	Direct electronic ignition
Injector size	NG: 1.15, 1.9, 1.8* LPG: 0.75, 1.15, 1.1* * only one point
Line pressure (min.)	NG: 1.13 kPa, LPG: 2.75 kPa
Line pressure (max.)	3.5 kPa (maximum standing pressure under abnormal intermittent conditions is 5.0 kPa). In the case of commercial metering (i.e. 35-37 kPa coming in), there may be a requirement to regulate the incoming line pressure down.
Power consumption	Normal: LPG – 62 W, NG – 51 W Automatic frost protection: 170 W Standby: 2.4 W
Noise level	50 dB(A)
NO_x af	< 60 ppm
Safety devices	Flame failure, boil-dry protection, overheat protection (OHS), fusible link, pressure relief valve, combustion fan rpm check
Water supply	Nominal operating pressure: 240-1000 kPa Minimum water flow: 1.5 litres per minute
Weight	32 kg
Market release	July 2011
Compliance	ES: Supplier Declaration of Compliance • Declaration Number: 1008720096 • Certificate Number: 7083
